AUTOSTORR

The super light-weight, flexible and impact-resistant partition wall with a Total thickness of 64 mm and a K-value of 0.48 K/m2W

Time is money. Daily ditribution activities in the tough, sometimes stressful everyday working life requires many conventional thermal partition walls.



Our STORRWALL AutoStorr thermal partition wall is the impact-resistant lightweight among partition walls. The core used, reinforced with fiberglass, makes the STORRWALL AutoStorr thermal partition wall extremely flexible and at the same time extremely impact-resistant.



The easily freely positionable and stowable STORRWALL AutoStorr thermal partition wall is easy on the back and automatically locks its position in the lowered and stowed state using the AutoLock mechanism. If the STORRWALL AutoStorr thermo partition is moved at an angle of about 45 °, the upper mechanism unlocks and the wall can be moved easily.



When stowed, the STORRWALL Auto-Storr thermal partition creates a minimal loss of storage height of only 120 mm. The balancing device is completely maintenance-free and is characterized in particular by a constant, non-declining performance.

Strong, Flexible

Strong, but still flexible. Thanks to the integrated fiberglass-reinforced frame within the partition core.

STORWALL - The smarterwall bends

Flexible glass fiber reinforced plastic profiles

In addition to the required stiffness, the GRP framework also provides great flexibility to the Autostorr.

Auto lock system

The lock is integrated in the balancers and automatically engages with a horizontal (stowed) and vertical position of the wall.In an angle of 45 degrees (between 30 and 60 de-grees ) the wall is effort-lessly movable through12 bearing wheels rolling in the STORR track.

Return ventilation hole

To remove vacuum when opening Autostorr and/or as extra ventilation option to feed second compartment with cold air. Hole opening can be adjusted by the variable positioning option of the closing flaps.

Built-in      fan-kit

12 or 24 volts Ventilator (optional) for dividing walls with a minimum thickness of 60mm (eg Autostorr and T-800).

Complete with thermostat with digital readout/setting of the (desired) temperature.

Includes Spiral cable with 2-pin plug.

Capacity 1300 m2/h

STORR tracks

STORR aluminum tracks for mounting directly on top in the corners.

Central assembly

In certain constellations, installation on the vehicle ceiling is recommended. Here we deliver an additional mounting bracket to attach the STORR aluminum running rail.

Wall stoppers

The use of the wall can be restricted with the rail stoppers.

Balancing system

Our maintenance-free balancing device - a lifting system made of aluminum, plastic and stainless steel - enables easy handling, no matter how often you have to open or close the partition. High-quality materials ensure a long service life and smooth use. We grant a 5-year guarantee on the balancing device if used properly!

Material

The unique AUTOSTORR partition wall contains extremely flexible, specially made insulation foam cores. The core material has a high impact resistance and does not absorb water.

On the underside, the wall is protected against damage from roll containers and pallets by a reinforcement made of polycarbonate.

The guarantee for a long service life and high product quality.

Handling

In order to operate the AUTOSTORR partition wall with just one hand and without bending over, the pull handles are attached at an operating height that is easy on the back.


Brake fingers

The locking is normally carried out in a horizontal and vertical position, on request a free shift at 90 degrees or other constellations for different geometries is available.

A - standard

B - free at 90 degrees

C - Special lock
